Welcome to X Series.
The Camera Series that solves your X.
Share your wow with the world – our new series of PTZ cameras is on its way.
Designed to make awesome accessible, there is an X camera for everyone.
Packed with innovative tech and handy features.
You’re welcome!
X-Series Comparison Table.
| Feature | X1 | X1 Ultra | X4 Ultra | X5 Ultra |
|---|---|---|---|---|
| IMAGING | ||||
| Image Sensor | Sony 1/2.8” CMOS • FULL HD | Sony 1/2.8” CMOS • ULTRA HD | Sony 1 / 1.8” CMOS – ULTRA HD | Sony 1/2.8” CMOS • ULTRA HD |
| Lens | f=5.5mm - 110mm | f=4.1mm - 49.2mm | f=6.25mm - 125mm | f=5.4mm - 104mm |
| Optical Zoom | 20x | 12x | 20x | |
| Video Format | 1080p @ 60/50/30/25fps
720p @ 60/50/30/25fps |
2160p @ 30/29.97/25fps
1080p @ 30/29.97/25fps 720p @ 30/29.97/25fps |
2160p @ 60/59.94/50/30/29.97/25fps
1080p @ 60/59.94/50/30/29.97/25fps 1080i @ 59.94/50fps 720p @ 60/59.94 |
2160p @ 60, 59.94, 50, 30/29.97/25fps 1080p @ 60, 59.94, 50, 30/29.97/25fps, 720p @ 60, 59.94, 50fps |
| Horizontal angle of view | 55.8° (W) – 3.2° (T) | 70.28º (W) - 6.57º (T) | 60° (W) ~ 3.5°(T) | 56.6°(W)-3°(T) |
| Vertical angle of view | 32.2° (W) – 1.8° (T) | 42.06º (W) - 3.76º (T) | 35° (W) ~ 2.0°(T) | 32.5°(W)-1.7°(T) |
| Diagonal angle of view | 61° (W) – 3.64° (T) | 78.36º (W) - 7.5º (T) | 66.6°(W) ~ 4.0°(T) | 64.7°(W)-3.5°(T) |
| Aperture | F1.6 (W) ~ 3.5 (T) | F1.8 (W) ~ 2.68 (T) | F1.58 (W) ~ 3.95 (T) | F1.6 (W)-F3.6(T) |
| Focus | Auto, Manual | |||
| Exposure | Auto, Shutter Priority, Iris Priority, Manual | Auto, Shutter Priority, Iris Priority, Manual, BLC, WDR | ||
| Backlight Compensation | Yes | |||
| Shutter Speed | - | 1/1 - 1/10000s | ||
| Digital Noise Reduction | 2D and 3D Noise Reduction | 3D Noise Reduction | ||
| SNR | >50dB | ≥45dB | >50dB | |
| Effective Pixels | 2.07 MP | 8.29 MP | 8.42 MP | 8.46 MP |
| Filter Ring | - | - | - | ∅49mm |
| AI Tracking | Presenter | Presenter + Zone | Presenter | |
| MECHANICAL | ||||
| Pan/Tilt Rotation | ±175°, -90°～+90° | ±170°, -30° ~ +90° | ||
| Pan Control Speed | 0.1 - 80°/sec | 1.7 - 80°/sec | 0.1 - 200°/sec | |
| Tilt Control Speed | 0.1 -60°/sec | 1.7-60°/sec | 0.1 -200°/sec | |
| Preset Number | 255 presets | 128 presets, Speed Adjustable | ||
| Integrated Tally Light | Halo Style, RGB | HALO tally and rear number tally system | Halo Style, RGB | |
| Pan/Tilt Drive System | - | - | - | Ultra-fine Drive |
| Display | e-Ink 2.93” Display | e-Ink 2.16” Display | e-Ink 2.93” Display | |
| Quietness | - | - | - | Max 28dB at full speed pan |
| I/O INTERFACE | ||||
| Video Output Interfaces | HDMI, USB-C UVC 1.1, Network | 3G-SDI, HDMI, USB-C UVC, Network | 12G-SDI, HDMI 2.0, HDMI 1.4, USB-C UVC 1.1, 1Gb Network | |
| Video Compression Format | H.264, H.265 | |||
| Network Interfaces | 100M adaptive Ethernet port; POE IEEE802.3af, Wi-Fi IEEE 802.11ac | 1Gbps adaptive Ethernet port; PoE IEEE 802.3at, WiFi 6 2x2 MIMO (Optional Base station) |
1GbE adaptive Ethernet port; POE+ IEEE 802.3at | |
| Encoder Network Protocols | NDI|HX2, NDI|HX3, RTSP, RTMP | NDI®|HX2, NDI®|HX3, SRT, RTSP, RTMP | ||
| HDMI Decoder Network Protocols | NDI|HX2, NDI|HX3 | - | NDI®|HX2, NDI®|HX3 | |
| Control Interfaces | 10M/100M Ethernet, Wi-Fi IEEE 802.11ac, RS232 (input & output), RS485, TYPE-C(UVC1.1) | 1Gbps Ethernet, USB-C, RS-232 | 1GbE Ethernet, RS232 (input & output), RS422, TYPE-C(UVC1.1) | |
| Control Protocols | VISCA Baud Rate: 9600/4800/38400/2400, VISCA-IP, NDI | VISCA Baud Rate: 38400/9600/4800/2400, VISCA-IP, NDI®, ONVIF | VISCA Baud Rate: 38400/9600/4800/2400, VISCA-IP, NDI | |
| Analogue Audio | - | 3.5mm TRS Line input/Mic Input | 3.5mm (1/4") Mic In / Line In (Stereo) | Digital Audio | - | Embedded with Main and Secondary HDMI, 12G-SDI, Network Video, USB (UVC) |
| GENERAL PARAMETER | ||||
| Enivronmental Operation | - | Internal | ||
| Input Voltage | DC 12V, POE IEEE802.3af | DC 12V, POE IEEE 802.3at | DC 12V, POE+ IEEE 802.3at | |
| Input Current | 2.0A (Max.) | 5.0A (Max.) | 2.0A (Max.) | |
| Power Consumption | 13W (Max.) | - | 18W (Max.) | |
| Battery Capacity | - | 9450mAh | - | |
| Battery Operating Time (Per Charge) | - | Up to 6 Hours Run Time (Usage Dependent) | - | |
| Working Temperature | -10℃ ～ +40℃ | 0ºC ~ +40ºC | ||
| Working Humidity | 20% ～ 80% | |||
| Dimension (W*H*D) | 171.6*192.6*171.6mm/ 260*217*197mm (before/ after packing) | 140.2*188.9*203.2mm/ 295*245*254mm (before / after packing) | 185.7*171.9*200.90mm/ 271*275*245mm (before / after packing) | |
| Net and Gross Weight | 1.35kg/2.05kg (Net/Gross weight) | 1.43kg/2.096kg (Net/Gross weight) | 2.19kg (Net / weight) | 2.31kg/3.76kg (Net/Gross weight) |
| Price in USD | $995 | $1495 | $2195 | $2995 |
